Military-grade lithium boat batteries engineered for serious anglers and boaters who demand reliable power. Black Oak LED's LiFePO4 batteries deliver consistent performance with lifetime warranty coverage, veteran-operated quality, and IP69K waterproof protection exceeding marine industry standards.
Whether powering a 36V tournament bass boat trolling motor, center console electronics, or pontoon house battery system, these deep cycle lithium marine batteries outlast lead-acid alternatives by 5-10X while weighing 70% less. From weekend fishing to professional tournaments, Black Oak LED lithium trolling motor batteries provide the power you need without weight penalty or maintenance headaches.
Understanding Lithium Boat Battery Technology
LiFePO4 Chemistry: The Safest Lithium Option
Black Oak LED uses LiFePO4 (Lithium Iron Phosphate) chemistry because it's the safest and most stable lithium technology available. Unlike other lithium types that risk thermal runaway, LiFePO4 batteries remain thermally stable under extreme conditions—no fire risk, no toxic fumes, complete safety in enclosed marine spaces.
Why LiFePO4 matters:
- Thermal stability prevents dangerous overheating
- Non-toxic and environmentally safe
- Longest cycle life available (5,000+ cycles)
- Maintains 80% capacity after 10+ years
Superior Performance vs Lead-Acid
Traditional marine batteries lose voltage throughout discharge, reducing trolling motor power as batteries drain. Black Oak LED lithium batteries maintain full voltage until 99% discharged, delivering consistent power from full to empty—critical for trolling motor performance throughout your fishing day.
Performance advantages:
-
Usable capacity: 99% vs 50% for lead-acid
-
Weight: 31 lbs vs 75+ lbs (12V 100Ah comparison)
-
Charging: 2-3 hours vs 8-12 hours
-
Cycle life: 5,000+ vs 300-400 cycles
-
Lifespan: 10-15 years vs 2-4 years
Battery Management System Protection
Every lithium marine battery includes an intelligent BMS monitoring and protecting your investment 24/7, plus Bluetooth connectivity for smartphone monitoring.
BMS features:
- Over-voltage, under-voltage, over-current protection
- Over-temperature and short-circuit protection
- Cell balancing for maximum lifespan
- Real-time capacity, voltage, temperature tracking via Bluetooth
Choosing the Right Voltage System for Trolling Motors
12V Battery Systems
Best for: Small boats, kayaks, jon boats, backup electronics, fish finders, livewells, navigation lights, 30-55lb thrust trolling motors
A 12V system uses single batteries or multiple batteries in parallel (combining capacity while maintaining 12V). Simplest and most common configuration for small boat applications.
When to choose 12V trolling motor battery:
- Boats under 16 feet with 40-55lb thrust trolling motors
- Kayaks and small boats with minimal power needs
- House battery banks for electronics only
- Budget-conscious setups
Black Oak LED 12V options:
-
12V 50Ah for light use (4-6 hours)
-
12V 100Ah for medium use (8-10 hours)
- Parallel configuration for extended runtime
24V Battery Systems
Best for: Mid-size boats (18-22 feet), 70-80lb thrust trolling motors, flats boats, bay boats, bass boat applications
A 24V trolling motor battery system uses two 12V batteries in series (doubling voltage while maintaining amp-hour capacity). Provides more power without 36V system complexity, making it the sweet spot for many bass boat and bay boat applications.
When to choose 24V lithium battery:
- Boats 16-22 feet with 70-80lb thrust trolling motors
- Anglers fishing deeper water requiring sustained power
- Situations where 36V seems like overkill but 12V isn't enough
- Budget-friendly alternative to 36V systems with similar performance
Black Oak LED 24V setup:
36V Battery Systems
Best for: Tournament bass boats, large boats (20+ feet), 100-112lb thrust trolling motors, professional anglers, shallow water power
Maximum trolling motor power for precise boat control in all conditions. This 36V trolling motor battery configuration uses three 12V batteries in series or single 36V battery, delivering the thrust needed for large boats, windy conditions, and heavy current situations.
When to choose 36V lithium trolling motor battery:
- Tournament competition requiring maximum boat control
- Boats over 20 feet or heavily loaded with gear
- Shallow water fishing where you need high-speed spot-locking
- Professional guides running clients all day
- Anglers fishing large reservoirs with long runs between spots
Black Oak LED 36V options:
Lithium vs Lead-Acid Deep Cycle Marine Battery Comparison
| Feature |
Black Oak LED Lithium |
Lead-Acid Deep Cycle |
AGM Battery |
| Weight (12V 100Ah) |
31 lbs |
75+ lbs |
65 lbs |
| Usable Capacity |
99% |
50% |
70% |
| Charge Cycles |
5,000+ |
300-400 |
500-800 |
| Charging Time |
2-3 hours |
8-12 hours |
6-8 hours |
| Lifespan |
10-15 years |
2-4 years |
4-6 years |
| Maintenance |
Zero |
Weekly checks |
Zero |
| Voltage Consistency |
Flat until 99% |
Drops throughout |
Moderate drop |
Total Cost of Ownership (10 Years)
Lead-Acid Deep Cycle Path:
- Initial: $200 + 3 replacements = $800
- Maintenance supplies: $100
- Total: $900 + lost fishing time
Black Oak LED Lithium:
- Initial investment only (lifetime warranty)
- Zero maintenance
- Total: Initial cost, no replacements
Lithium deep cycle marine batteries pay for themselves through longer lifespan, zero replacements, and reduced charging time.
Battery Selection by Trolling Motor Thrust
| Motor Thrust |
Voltage |
Best Lithium Battery Configuration |
Runtime (50% throttle) |
| 30-40 lbs |
12V |
Single 12V 50Ah lithium battery |
6-8 hours |
| 40-55 lbs |
12V |
Single 12V 100Ah lithium battery |
8-10 hours |
| 55-70 lbs |
24V |
Two 12V 50Ah in series (24V 50Ah) |
5-7 hours |
| 70-80 lbs |
24V |
Two 12V 100Ah in series (24V 100Ah) |
8-10 hours |
| 80-101 lbs |
36V |
Three 12V 50Ah in series (36V 50Ah) |
4-6 hours |
| 101-112 lbs |
36V |
36V 60Ah trolling motor kit |
6-8 hours |
Complete System Packages
Tournament Bass Boat Package
Includes:
Best for: Professional anglers with 36V trolling motor systems and extensive electronics needing all-day power with separate battery banks.
Weekend Warrior Bass Fishing Package
Includes:
Best for: Recreational anglers with 24V trolling motors on 18-22 foot boats fishing 4-8 hour trips.
Pontoon Multi-Purpose Package
Includes:
Best for: Pontoon boats, small cruisers where single battery handles starting and house loads.
Kayak and Small Boat Package
Includes:
Best for: Fishing kayaks, jon boats, canoes with 12V trolling motors under 55 lbs thrust where weight and portability matter most.
Why Choose Black Oak LED
Veteran-Operated Military-Grade Quality
Black Oak LED brings military engineering standards to marine batteries. As a veteran-operated company, we build equipment with the same uncompromising reliability standards used when lives depended on performance.
Military standards applied:
- IP69K waterproof rating (highest marine protection)
- Extreme temperature operation (-40°F to 140°F)
- Saltwater corrosion resistance
- Vibration and drop testing
Lifetime Warranty Beats Competitors
While other manufacturers offer 10-11 year warranties, Black Oak LED backs every battery with lifetime warranty. Complete replacement if capacity drops below 80%, no prorated charges, transferable to second owner.
Complete Marine Power Solutions
Only manufacturer offering both professional marine LED lighting and lithium boat batteries. Upgrade your boat's entire electrical system with products engineered to work together.
Available systems:
Florida Saltwater Testing
Every product undergoes real-world testing in Florida's harsh marine environment—Gulf Coast salt spray, Intracoastal brackish conditions, extreme heat, and hurricane-force conditions.
Upgrading from Lead-Acid to Lithium
Drop-In Replacement
Black Oak LED lithium marine batteries directly replace Group 24, Group 27, and Group 31 lead-acid batteries. Physical dimensions match standard sizes for straightforward installation in bass boats, pontoons, and center consoles.
Requirements:
- Charger with LiFePO4/lithium profile (most modern chargers include this)
- Same terminals, mounting, wiring gauge
- If charger lacks lithium mode, upgrade to lithium-compatible charger
Charger Compatibility
Lithium-specific chargers required with proper charging profiles for LiFePO4 batteries:
- 14.4V-14.6V charging voltage (vs 14.8V+ for lead-acid)
- CC/CV (constant current/constant voltage) algorithm
- Temperature compensation
- Automatic shutoff when full
Available chargers:
Installation Time
Simple replacement (single battery): 30 minutes Series configuration (24V/36V trolling motor): 1-2 hours Complex systems (separate banks): 2-3 hours
Professional installation available—contact Black Oak LED at 1-800-348-1287 for guidance.
Cold Weather and Storage
Temperature Performance
Black Oak LED batteries operate from -40°F to 140°F. Discharge works fine in freezing temperatures, but charging is blocked below 32°F by BMS protection (prevents lithium plating damage).
Cold weather operation:
- Use trolling motor in freezing temps without issues
- Cannot charge below 32°F (warm battery first)
- Capacity returns to 100% when warmed
- Optional self-heating models available for extreme cold
Storage Best Practices
Short-term (1-3 months):
- Charge to 50-70%
- Disconnect from boat
- Store above freezing
- Check monthly
Long-term (3-6 months):
- Charge to 50% (not full)
- Store at 40-80°F
- Check every 3 months
- BMS self-consumption <3%/month
Why 50% storage: Prevents cell degradation, reduces stress, industry standard for lithium storage.
Installation and Setup
Series vs Parallel Connections
Series (increases voltage for trolling motors):
- Connect positive to negative between batteries
- Example: Two 12V 50Ah = 24V 50Ah trolling motor battery
- Use for 24V/36V trolling motors
Parallel (increases capacity):
- Connect all positives together, all negatives together
- Example: Two 12V 50Ah = 12V 100Ah
- Use for extended 12V runtime
Safety notes:
- Use identical batteries (same model/age)
- Proper wire gauge for current
- Inline fuses for protection
- Label connections clearly
Wiring and Fusing
Wire gauge by current:
- 30A: 10 AWG minimum
- 50A: 8 AWG minimum
- 75A: 6 AWG minimum
- 100A+: 4 AWG or larger
Fusing: Place fuse near battery positive, size 25% above operating current, use ANL or MRBF marine-rated fuses.
Maintenance and Care
Daily Checks
- Check Bluetooth BMS for battery status
- Verify adequate charge level
- Look for terminal corrosion
- Ensure secure mounting
Cleaning (Quarterly)
- Disconnect negative first, then positive
- Clean terminals with baking soda solution
- Rinse with fresh water, dry completely
- Apply dielectric grease
- Reconnect positive first, then negative
Troubleshooting
Won't charge:
- Check temperature (must be above 32°F)
- Verify charger has lithium profile
- Test charger output
- Inspect connections
Lower runtime:
- Verify voltage match with trolling motor
- Check for additional loads
- Cold weather reduces capacity temporarily
- High speeds drain faster
Frequently Asked Questions
How long do lithium boat batteries last?
Black Oak LED lithium marine batteries last 10-15 years with 5,000+ charge cycles, backed by lifetime warranty. If you fish twice weekly year-round (100 cycles/year), theoretical life exceeds 50 years. Real-world lifespan depends on usage and storage. Lead-acid deep cycle batteries last 2-4 years with 300-400 cycles.
What is the best lithium battery for trolling motor?
The best lithium battery for your trolling motor depends on motor thrust and voltage system. For 30-55lb thrust motors, use 12V 100Ah. For 70-80lb motors, use 24V system (two 12V batteries in series). For 100-112lb motors, use 36V system. Black Oak LED's LiFePO4 batteries provide consistent power delivery critical for trolling motor performance.
Can I replace lead-acid with lithium directly?
Yes, Black Oak LED batteries are drop-in replacements for Group 24/27/31 lead-acid. Verify your charger has LiFePO4/lithium profile. Most modern marine chargers include lithium modes. Physical installation identical—same terminals, mounting, wiring.
What size lithium battery for trolling motor?
Match battery voltage to motor system (12V/24V/36V), then choose capacity by fishing duration. For 12V motors under 55 lbs, 50-100Ah provides 6-8 hours at 50% throttle. For 24V motors (70-80 lbs), two 12V 100Ah batteries give 8-10 hours. For 36V motors (100-112 lbs), three 12V 50Ah or one 36V 60Ah provides 4-6 hours.
Do lithium trolling motor batteries work in cold weather?
Batteries discharge normally to -40°F, so trolling motors work in freezing weather. Cannot charge below 32°F (lithium plating damages cells). Bring batteries inside to warm before charging, or choose self-heating models for extreme cold.
How do I maintain lithium marine batteries?
Zero maintenance vs lead-acid's weekly water checks. Store at 50% during winter, check charge every 3 months, keep terminals clean annually. Built-in BMS protects automatically. Bluetooth monitoring checks battery health from phone.
What is a LiFePO4 marine battery?
LiFePO4 (Lithium Iron Phosphate) marine batteries use the safest lithium chemistry available. Unlike other lithium types, LiFePO4 batteries remain thermally stable under extreme conditions with no fire risk. Black Oak LED uses LiFePO4 chemistry in all marine batteries for maximum safety and 5,000+ cycle lifespan.
How much do lithium boat batteries cost?
Lithium boat batteries range from $300-1,500 depending on voltage and capacity. While more expensive than lead-acid initially, they last 5-10X longer (5,000+ cycles vs 300-400). Black Oak LED batteries include lifetime warranties, making total cost of ownership lower than lead-acid over 10 years.
Can I use my existing charger with lithium batteries?
Only if charger has LiFePO4/lithium profile. Check manual for "lithium" or "LiFePO4" modes. Traditional lead-acid chargers use 14.8V+ that damages lithium. Black Oak LED offers lithium-compatible chargers with proper voltage limits.
What is the best trolling motor battery for 80 lb thrust?
For 80lb thrust trolling motors, use 24V system with two 12V 100Ah lithium batteries in series (24V 100Ah total). This provides 8-10 hours runtime at 50% throttle. Black Oak LED's 12V 100Ah batteries deliver consistent power throughout the discharge cycle.
The Black Oak LED Advantage
When mission-critical reliability matters, trust the veteran-operated company that builds equipment for professionals who depend on performance. Black Oak LED lithium boat batteries deliver consistent power, lifetime warranty, and military-grade construction exceeding marine standards.
Need complete boat power and lighting? Explore our marine LED light bars for bow, stern, spreader lighting, or LED light pods for underwater illumination. Black Oak LED offers both marine lighting and lithium batteries engineered to work together.
Questions about battery selection? Call 1-800-348-1287 to speak with a marine power specialist.
From weekend warriors to professional tournament anglers, Black Oak LED powers the boats that win.
